4MP Entry IR Fixed-focal Bullet Network Camera
> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition
> Outputs 4MP (2560 × 1440) @25/30 fps, and supports max. 4MP (2688 × 1520) @20 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in IR LED, max. IR distance: 30 m
> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
> Image Rotation, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access, voltage detection
> 12V DC/PoE power support
> IP67, protection
| Camera | |
|---|---|
| Image Sensor | 1/3” 4Megapixel progressive CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| S/N Ratio | > 56 dB |
| Lens | |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8 mm / 3.6 mm |
| Max. Aperture | F2.0 |
| Field of View | 2.8 mm: Horizontal: 93°, Vertical: 53°, Diagonal: 111° 3.6 mm: Horizontal: 81°, Vertical: 44°, Diagonal: 95° |
| Video | |
| Video Compression | H.265, H.264, H.264B, MJPEG |
| Smart Codec | Smart H.265+/Smart H.264+ |
| Stream Capability | 2 streams |
| Resolution | 2688 × 1520, 2560 × 1440, 2304 × 1296, 1080p, 1.3M, 720p, D1, VGA, CIF |
| Network | |
| Network | RJ-45 (10/100 Base-T) |
| Protocol | HTTP, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, etc. |
| Power | |
| Power Supply | 12V DC/POE (802.3af) |
| Power Consumption | < 5W |
| Environment | |
| Operating Conditions | -40°C to +55°C (-40°F to +131°F) / ≤95% |
| Storage Conditions | -40°C to +60°C (-40°F to +140°F) |
| Protection | IP67 |
| Structure | |
| Casing | Metal + Plastic |
| Dimensions | 162.6 mm × Φ70 mm (6.4″ × Φ2.8″) |
| Net Weight | 0.22 kg (0.5 lb) |
